M1-B Optic Mount for AK-47 w/o side gas ports (Seconds)


For AK type rifles that have original gas tubes without side gas port holes.
Model# M1-B-Seconds

Availability: In stock

SKU: M1-B-Seconds Category:

Mounts sold under this category are discounted because they have minor blemishes (this kind of merchandise is also referred to as “seconds”). They have flaws that are cosmetic, but do not impact the mount’s functionality. Each blemished mount has its own imperfections, which may include small scratches, pitting in the anodizing finish, and slight discoloration of the finish.

The appearance of these blemished mounts can vary widely; the photos above show some possible flaws one may expect on these particular M1-B mounts. The mount on the left has small scratches along the picatinny rail. The mount on the right has less visible scratches but also has very minor discoloration. Also note that most of these M1-Bs feature a different picatinny rail profile, as you can see in the mount on the left. This is found in our older versions of AK mounts. They function just like our current versions.

UltiMAK AK Scout Mount

For standard length, standard weight AKs/AKMs, that have original gas tubes without side gas port holes.

  • Clamps rock-solid to barrel for maximum stability and accuracy.
  • Replaces the gas tube/upper handguard assembly.
  • Includes steel clamps, screws, Allen wrench, and instructions.
  • Easy installation: no gunsmithing required.
  • Made in U.S.A.

Construction: Solid, one-piece 6061-T6 hard anodized aluminum body.
Rail: Picatinny style (16 slots).
Length: 6.875″

Model# M1-B-Seconds

UltiMAK M1-B: A rock-solid platform for your premium optics. With the increasing popularity of the AK based rifles in three gun competitions, the need for a handy, light, completely reliable high speed sighting system has resulted in the UltiMAK M1-B optic mount. Its Picatinny style rail is positioned well below the iron sight axis, making this the lowest optic mount available for the AK. With a tubular sight mounted low, you will be able to use your optic without a comb riser and still use your regular hold. The system allows for co-witnessing (the ability to use your iron sights right through a 1x sight as a back-up sighting system) when used with a tubular reflex sight. This heavy duty mount replaces the original steel gas tube and upper handguard, so it adds less than one ounce to the weight of the rifle, making it by far the lightest optic mount installation in the world. The forward positioning of the optic gives you faster, easier and more natural targeting while maintaining your full field of view. Multiple target or moving target engagements, with both eyes open, become second nature.

Romanian Small Bore AKs Only: Romanian 5.45 and 5.56 mm caliber AKs require our shim set SH-1 to match the M1-B to the smaller barrel. Other European and Chinese small bores will NOT need the shims.

The UltiMAK AK optic mount rarely if ever needs to be removed to clean the rifle, so you need not worry about loss of zero. Since the mount is clamped to the barrel and not jammed in between the gas block and the sight block like the original gas tube, several UltiMAK users have reported an improvement in their AKs’ inherent accuracy.

Shown here the M1-B is installed on an Egyptian rifle with a Choate Dragunov style stock.

M1-B on Egyptian AK

Will the UltiMAK Optic Mount fit my rifle?
(More details on the interchangeability of the UltiMAK design)
